125KHZ And 13.65MHZ Dual Frequency RFID China Smart Card Manufacturers

smart card manufacturers

Model No.: CXJ-SRC-DFSRC-0001
Brand: CXJ
Material: PVC
Surface: glossy, matte, frosted
Size: 86*54*0.84mm, or customized size
Printing: customer logo and color are avaiable



Smart Card Manufacturers:

Shenzhen Chuangxinjia Smart Card Co, Ltd. found in year 1999, which is a collection of design, produce, sales for the integration of smart card manufacturers. Our company have strong capacity of PVC cards, such as magnetic stripe card, membership card, gifts card, luggage tag, etc. We have 3 modern production line with monthly output 40,000,000 pcs PVC card. RFID end product production line with monthly output of 8,000,000 smart card and 6,000,000 RFID tag.


Material: PVC
Surface: glossy, matte, frosted
Size: 86*54*0.84mm, customized size is available
Color: Full color printing
Extra Crafts: Serial number printing, logo printing, data encoded etc
Chip options: LF, HF, UHF

1.MIFARE Classic®1K   MIFARE Classic®4K
MIFARE and MIFARE Classic are trademarks of NXP B.V. and are used under license.

2.MIFARE Ultralight®MIFARE Ultralight®C
MIFARE and MIFARE Ultralight are registered trademarks of NXP B.V. and are used under license.

MIFARE DESFire are registered trademarks of NXP B.V. and are used under license

4.MIFARE Plus®
MIFARE and MIFARE Plus are registered trademarks of NXP B.V. and are used under license.

Package: 100 pcs/opp bag and 5000 pcs/carton
Lead time: 8-9 days base on quantity
Shipping way: by express(DHL,FEDEX), by air, by sea
Price term: by EXW,FOB,CIF,CNF
Pay term: by TT,western union,paypal,etc
MOQ: 500 pcs
Sample: Free exist samples and shipping cost collection by customer


The dual frequency passive RFID cards are come in three combinations: HF-UHF, HF-LF and UHF-LF. The HF inlay is in accordance with the ISO 14443 standard (which can also be used for NFC applications), while the UHF inlay complies with the ISO 18000-6C standard and the LF inlay operates at 125 or 134 kHz compliant with proprietary air-interface standards for access control.

Dual frequency rfid smart card combines two different RFID frequencies to get the best of both technologies. The merchandise may combine the UHF Gen 2 functionality for long read ranges with HF or LF technologies that offer compatibility with formerly current techniques, large user memory, high-security functions and, thanks to the shorter read ranges, advantages in terms of privacy. Additionally HF/LF can be provides. The Alien Technology Higgs-3 is the chip used for the UHF part, while the most used HF ICs consist of: NXP ICODE SLI (ISO 15693), Legic Prime MIM256 (proprietary), NXP MIFARE Classic 1K (ISO 14443 A) and NXP MIFARE DESFire EV1 (ISO 14443 A). Personalization providers include various types of printing, laser engraving, slot punching and magnetic stripe.

A dual frequency rfid card has long been anticipated by the marketplace to unleash the full power of RFID. By providing the equipment that expand the RFID value chain to include the ability for brand manufacturer to immediately connect to the end customer is a milestone event for the whole business. To combine all the benefits of UHF and NFC into a single chip tag is undoubtedly an exquisite resolution. To embrace the latest ISO standards for maximum security in both frequencies opens doors to opportunities beyond the retail store originally targeted and into the pharmaceutical, nutraceutical as well as healthcare spaces. China smart card is one of the mian product of our company, and we are the best smart card manufacturers in China.
